Sinilink XY-BS750 Adjustable Boost Module Voltage Converter 8-32V Reverse Polarity Over Current Temperature Protection Dedicated Power Supply for Audio Amplifiers with Display
The Sinilink XY-BS750 Adjustable Boost Module Voltage Converter 8-32V Reverse Polarity Over Current Temperature Protection Dedicated Power Supply for Audio Amplifiers with Display is a mid-range product designed for everyday users.
Available Offers
Free Delivery on this order. No minimum order value.
15-Day Easy Returns — hassle-free return & full refund.
Secure Payment — 100% safe checkout with UPI, Cards & Net Banking.
25% Off — you save ₹710 on this product!
Available Offers
5% Cashback
Pay with UPI & get 5% cashback (up to ₹50) via Razorpay
No-Cost EMI
Available on select bank cards at checkout. 0% interest for 3 months.
Free Shipping
Free delivery on all orders. No minimum order value.
Cash on Delivery
COD available on orders up to ₹5,000 across India.
Ideal For
About This Product
The Sinilink XY-BS750 Adjustable Boost Module Voltage Converter 8-32V Reverse Polarity Over Current Temperature Protection Dedicated Power Supply for Audio Amplifiers with Display is a mid-range designed for everyday users. It delivers reliable performance at an accessible price.
Why Buy from Pricio?
Pricio sources this product directly, cutting out multiple middlemen. Every order includes free shipping, a 15-day return policy, and secure payment via Razorpay.
Specifications:
XY-BS750:
Input Voltage: DC 8-32V (Under-voltage protection triggers below 7V; damage may occur above 35V).
Output Voltage: Adjustable from Vin to ~55V (continuously adjustable).
Rated Power: 900W (Peak Power: 1100W).
Input Current: Maximum 30A with over-current protection.
Quiescent Current: 60mA at Vin=20V, Vout=48V.
Input Features: Reverse polarity protection: 120A, 7.5mΩ TO220 high-power MOSFET.
Protection Functions:
Under-voltage protection: 7V.
Over-current protection: 30A.
Over-voltage protection: Lockout at 59V (requires power cycle for reset).
Over-temperature protection: Activates at 100°C.
Cooling System: 40mm×40mm forced air fan + dual heat sink (40×35×8mm).
Output Voltage Display: Accuracy 0.1V (optional to turn off).
Ripple Performance:
No-load ripple: ±30mV.
Full-load ripple: ±150-250mV (outperforms competitors exceeding ±600mV).
Temperature-Controlled Fan Activation: Fan turns on when baseplate exceeds 40°C.
XY-BS1500:
Supply Voltage: DC 8-32V (Under-voltage protection triggers below 7V; damage may occur above 35V)
Output Voltage: Adjustable from Vin to ~55V
Output Power: Rated Power: 1500W / Peak Power: 1800W
Input Current: Maximum 50A (with over-current protection)
Quiescent Current: 60mA (at Vin=20V, Vout=48V); increases with higher output voltage
Input Reverse Polarity Protection: 130A, 6mΩ, TO247 footprint high-power MOSFET
Input Under-Voltage Protection: Enabled at 7V
Input Over-Current Protection: Enabled at 50A
Output Over-Voltage Protection: Software protection with 59V over-voltage lockout; requires power cycle to reset
Over-Temperature Protection: Activates when baseplate temperature exceeds 100°C
Cooling Method: 60mm60mm fan forced air, 6035*8mm dual heat sink
Output Voltage Display: Display accuracy ±0.1V (can be turned off)
Temperature-controlled Fan Activation Condition: Fan activates when baseplate temperature exceeds 40°C
Output Ripple: No-load ripple: ±30mV; Full-load ripple: ±150-250mV (Competitive products typically exceed ±600mV)
XY-BS3000:
Supply Voltage: DC 12-60V, under-voltage protection activated below 11V
Output Voltage: Vin to ~90V, continuously adjustable
Rated Power: 3000W (Peak Power: 3500W)
Input Current: Maximum 50A (with over-current protection)
Quiescent Current: 60mA at Vin=20V, Vout=48V
Protection Features: Reverse Polarity, Under-Voltage, Over-Current, Over-Voltage, Over-Temperature
Cooling Method: 60mm x 60mm fan with forced air + Dual heat sink (60 x 35 x 8mm)
Output Voltage Display: Accuracy of 0.1V, with the option to turn off
Fan Activation Temperature: 40°C baseplate temperature
Output Ripple: No-load ripple ±30mV, Full-load ripple ±150-250mV
Package Included:
1 x High-Power Boost Converter Module
