IRF520 MOS Driver Module PWM Dimmer 0-24V Top Mosfet Button IRF 520 for ArduinoMCU ARM Raspberry Pi
The IRF520 MOS Driver Module PWM Dimmer 0-24V Top Mosfet Button IRF 520 for ArduinoMCU ARM Raspberry Pi is a value-for-money product designed for everyday users.
Available Offers
Free Delivery on this order. No minimum order value.
15-Day Easy Returns — hassle-free return & full refund.
Secure Payment — 100% safe checkout with UPI, Cards & Net Banking.
45% Off — you save ₹507 on this product!
Available Offers
5% Cashback
Pay with UPI & get 5% cashback (up to ₹50) via Razorpay
No-Cost EMI
Available on select bank cards at checkout. 0% interest for 3 months.
Free Shipping
Free delivery on all orders. No minimum order value.
Cash on Delivery
COD available on orders up to ₹5,000 across India.
Ideal For
About This Product
The IRF520 MOS Driver Module PWM Dimmer 0-24V Top Mosfet Button IRF 520 for ArduinoMCU ARM Raspberry Pi is a value-for-money designed for everyday users. It delivers reliable performance at an accessible price.
Why Buy from Pricio?
Pricio sources this product directly, cutting out multiple middlemen. Every order includes free shipping, a 15-day return policy, and secure payment via Razorpay.
Specifications:
Size: 33.4*25.6MM
Weight: 10g
Voltage: 3.3V, 5V
Port: the digital quantity level
The output load voltage: 0 to 24V
The output load current: < 5A (more than 1A need to add heat sink)
Platform: for MCU, ARM, raspberry pie
Features:
1. Using original IRF520 power MOS tube, can adjust PWM output
2. Can let the for arduinodrive up to 24V load, such as LED lights belt, dc motor, micro pump, solenoid valve
3. By PWM adjustable can realize stepless dimming LED, motor stepless speed regulation
Package Include:
1x Module Board
The product instructions:
PWM signal for high level effectively
When the PWM for high level (3.3 V to 3.3 V) :
As the power supply voltage, between V + and V - working indicator, work load
When the PWM is low level (0 V to 0.5 V) :
V + and V - between 0, work lights out, don't work load
